SUMMA Band Saws with Sliding Carriage Range
price from £POA+VAT
Band Saw with carriage
Suitable for cutting wood, beams, insulating materials and much more
It guarantees safety for the operator and very high precision
STANDARD EQUIPMENT
CE
- 400V/3/50 Self-braking Motor
- Upper and Lower Bearing Blade Guide for Blade Widths from 15 to 45mm
- Automatic Star-delta Starter
- Solid Flywheels (1/3 crowned in the front) Without Rubber
- Bronze Scrapers on Flywheels
- Gravity-fed Blade Lubrication System on Felt Pad
- Blade Tension Gauge
- Rack and Pinion Blade Guide Raising with Incorporated Blade Protection
- Trimming Support Table
- Increase Motor Power is Available
Available with 1500, 2000, 2500, 3200 or 3700mm Carriage
Specification
| 740 2" 1500/3200/4300 |
740 3" 1500/3200/4300 |
840 2" 1500/3200/4300 |
940 2" 1500/3200/4300 |
940 3" 1500/3200/4300 |
940 3" Special 1500/3200/4300 |
|
| Flywheels Diameter | 730mm | 730mm | 830mm | 930mm | 930mm | 930mm |
| Motor Power HP | 7.5hp (5.5) | 10hp (7.5) | 7.5hp (5.5) | 15hp (11) | 15hp (11) | 15hp (11) |
| Blade Speed | 1600m/min - Different speed: on request | |||||
| Cutting Height Max. | 500mm | 500mm | 560mm | 570mm | 620mm | 620mm |
| Cutting Width | 710mm | 710mm | 810mm | 910mm | 910mm | 700mm |
| Blade Width Max. | 45mm | 80mm | 50mm | 55mm | 90mm | 90mm |
| Blade Length | Min:5300 - Max:5400mm | Min:5310 - Max:5420mm | Min:6000 - Max:6100mm | Min:6590 - Max:6690mm | Min:6580 - Max:6670mm | Min:6580 - Max:6670mm |
| Dust Suction Outlets | 2 x Ø 140mm | 2 x Ø 140mm | 2 x Ø 140mm | 2 x Ø 140mm | 2 x Ø 140mm | 2 x Ø 140mm |
| Carriage Dimensions | ||||||
| 1500 | 315 x 1500mm | |||||
| 2000 | 315 x 2000mm | |||||
| 2500 | 315 x 2500mm | |||||
| 3200 | 315 x 3200mm | |||||
| 3700 | 315 x 3700mm | |||||
Optional Accessories
